MPT-VARIO joints

MPT-VARIO joints

galvanised and hot-dip galvanised

Display variants as list

For profiles:

Q50-2.5, Q100-2.5, Q100-3.5, Q150-2.5 Q80-2.0

Field of application

Reinforced joint angles for corner and angle connections as well as for bracing in combination with MPT-Support profiles Q50, Q80, Q100 and Q150
Additional connection options due to fourfold perforation

Advantages

Flexible connecting element for connecting MPT-Support profiles with any connection angles
Any tolerances that may occur can be compensated due to oblong holes in mounting angles

Design:: 180°
Product type:: Connecting parts
Support channels:: for MPT-Profiles

MPT-VARIO joints

	Product number	For profiles
	166944	Q50-2.5, Q100-2.5, Q100-3.5, Q150-2.5
	167939	Q80-2.0
